Overview
The MS23 is a high precision magnetic linear position sensor head with 2 micron resolution and quadrature output.

The MS25U integrates a high speed processor, reflective limit switches and general digital/analog IO with a high precision magnetic sensor head with 2 micron resolution.

Features
    o  Magnetic Sensors integrated on one PCB
    o  Reflective limit switches integrated with sensor head
    o  MS25U has USB 2.0 interface
    o  On board high performance processor with A/D, D/A and digital IO
    o  Example application included for rapid application development
    o  1.8-3.6VDC power input
    o  Extremely Small form factor (1.50x1.15 in)

Description
The MS23 is a high performance magnetic linear position sensor head with quadrature output.

The MS25U is a high performance magnetic linear position sensor with USB 2.0 output.

Related Products
The following products can be used with the MS23, MS25U:

    Quad3X           3-Axis Quadrature Decoder

   Quad6X            6-Axis Quadrature Decoder


Downloads/Revisions
The following technical datasheets, hardware and software downloads are available.
